Oxygen concentration sensor is an instrument for measuring the oxygen partial pressure per unit by electrochemical or spectral analysis or ultrasonic principle. It can be used for the determination of oxygen concentration in the medical industry, the detection of plant respiration, and the detection of respiration in the storage of food, fruits and vegetables in the agricultural field. The normal oxygen content of the oxygen detector should generally be between 19.5% and 23% VOL, and the specific standard value should be 20.9% VOL. In other words, the volume fraction of oxygen in the air should be within that range. If the detected value is lower or higher than that range, the oxygen detectors should be able to give timely and accurate alarm.
Oxygen is an indispensable element for our human survival. It is often necessary to detect the oxygen concentration in various scenes of various industries such as industries and fire safety. However, with the development of technology, there are more and more methods for detecting the oxygen concentration in the environment, and they are more and more advanced. As the application of industrial processes requires improving the measurement accuracy and repeatability, users also require little maintenance and calibration of gas analyzers. Therefore, users of oxygen analyzers are encouraged to evaluate the advantages of specific oxygen sensor types according to their expected applications. There is no universal oxygen sensor type.
Measuring range of oxygen concentration sensor
0-30%vol is used for human safety detection to prevent people from being deprived of oxygen, which is the most common measuring range.
0-25%vol is used for detecting the combustion efficiency in combustion emission of industrial waste gas from boiler, and monitoring the oxygen content index in the combustion furnace. Generally, this requires the oxygen detector based on high-temperature zirconia principle.
0-100%vol is used for purity detection of oxygen generator and oxygen concentration detection in medical industry, which are the measurement ranges of oxygen detectors that need high concentration.
0-5%vol is mostly used for waste gas treatment in industrial pipelines. The purpose is to control the oxygen content not to exceed the standard, and otherwise it will easily lead to explosion accidents caused by the catalytic effect of oxygen, so it is very important to control the oxygen content.
0-10,000 ppm/0-1,000 ppm belongs to the detection field of trace oxygen, which is mainly used for evacuating the equipments, or in high-risk industrial fields, where oxygen control is extremely high.
0-1000ppm/0-100ppm, which is extremely demanding oxygen content monitoring standard, has high detection accuracy for the whole oxygen detector. What is the concept of this measuring range? PPM is a proportional unit of one millionth. Therefore, this is an extremely small concentration. This measurement range of trace oxygen is also used in the detection of high-purity nitrogen, in order to verify the purity of nitrogen. And the oxygen content in nitrogen is detected to determine whether the purity of nitrogen reaches 99.999%, that is the popular five 9-purity nitrogen application fields.
